Fan Heaters
(Original instruction)
General for A + B
PermanentInstallation(xed)The
heatercanbeinstalledhorizontally
oratadownwardgradientof15°.
Operation panel must be visible from
1meterdistance.
1.Thexingsareattachedtothe
housingbyuseof4screws.Thetwo
spacingwashersareplacedbetween
thehousingandtubularframe(inthe
bottomhole).
2.Marktheholepositions.Drillout
4holestoattachthexingtothe
wall.UseM8screws.
3.Nowxtheheaterinthetop
screwsandattachthebottom
screws.
Use of DELTA - List of signs
O󰀨
Fan on
 Halffanandhalfheat
 Fullfanandhalfheat
 Fullfanandfullheat
DELTAfanheatersrequireno
maintenance.However,itis
recommendedtocleanthefan
heaterfromdustbymeansof
compressed air after long time of use
orafteruseindustyrooms.
Timer
Tosettimedelay,rotatetheknob
clockwiseandthenturnback
anticlockwise to required setting
Electrical Installation
Installationmustbecarriedoutwith
anall-poledisconnectionwitha
contact space measuring at least
3mmperpole.Permanent
installation must always be
performedbyanauthorized
electricianinaccordancewithcurrent
regulations.Onlytheelectricianhas
knowledgeofcurrentregulations.
Theterminalsareaccessibleifthe
screwsandtheplateontheright
sideareremoved.
Preservation and storage
Theunitsmustbestoredunderthe
following conditions:
•relativehumiditymaximum60%
• temperature minimum 15°C
