VS5HI VOLTMETER SEUENCER - INSTRUCTION MANUAL

CONGRATULATIONS!

You have just purchased a product with the quality

JFA Electronics, which was developed with

technology advanced and unique design.

Please read the operating instructions and

installation in this guide.

PRESENTATION

The voltmeter and sequencer VS5HI JFA was

developed to perform three functions in the same

equipment they are:

• Low voltage voltmeter to 17V;

• High-voltage voltmeter up to 500V;

• Remote command sequencer.

DESCRIPTION

1 - Selector functions: HOL (Hold) - LIG (ON) - OFF

2 - Voltmeter selector: LOW - HIGH;

3 - Five remote control outputs;

4 - High input voltage (battery bank);

5 - GND;

6 - Remote control input;

7 - Low input voltage (+12V).
