3
Part names 1.2
Standard mounting attachment
Insulation screw
Figure 1.2 Cable type (ARO-FT)
Figure 1.1 Standard type (ARO-FT)
Main Unit
Oxygen detection film
Temperature sensor
Lock-nut
Locking sleeve
LEMO connector
Figure 1.3 MCBH type (AROD-FT)
MCBH connector
