Getting Started with the RL1
www.jgroptics.com
• Press once: power on
or reset the wireless
connection
• Press and hold for 7
seconds: power off
M12 input (from 2
nd
RD-S) M12 output (to RL1)
Micro-USB charging port
• Press once: reset
network settings
• Do NOT press and
hold for > 5 seconds
M12 input (from RD-S)
USB-B to PC USB-A to peripherals
ex: SX1 switch, barcode scanner, etc
Ethernet port
