Shanghai Jiashen Technology Co.，Ltd.
JS-C33
Shanghai Jiashen Technology Co.，Ltd.
2017-2017COPYRIGHT
1- -：Quick change battery type
Under this menu, you can change the default parameters quickly，The L represents the lithium battery, and the
latter figure is the series quantity of the lithium battery, P stands for lead-acid batteries, and the numbers behind
represent voltage.
Set step：Enter the menu 1--, as shown in P 3, and display 1—L/P/F xx, Click the button to switch between
F, P, and L. Press the button to change the parameters, select the appropriate battery
specifications.After selection, press the button to save it. If you don't need to change other
parameters, hold the button for a little long time to quit.
For example：L3 represents 3 string lithium 4.2V*3S=12.6V
L4 represents 4 string lithium 4.2V*4S=16.8V
F4 represents 4 string LiFeCoPO4 3.2V*4S=12.8V
F8 represents 8 string LiFeCoPO4 3.2V*8S=25.6V
P12V stands for lead-acid 12V batteries
P24V stands for lead-acid 24V batteries
Note: If you choose the battery specifications and the actual battery
specifications are different, The percentage value cannot be
used as a reference value for the remaining battery power.
the voltage value is the current battery voltage.
All parameters must be saved at the last time.
Detailed Submenu function：
Go into settings mode：
1， Turn on the machine, press the button for 5 seconds, enter the
main menu, as shown in Figure P 2.
2， The main menu has 5 sub menus:1--，2--，3--，4--，5--。
3， Press the button , and the 5 submenu loops.
4， Each function of the 5 sub menu：
1- -: Select lithium battery or lead acid Battery or LiFeCoPO4 Battery
2- -: Setting Delay Time Delay OFF/ON,and select Delay Time
3- -: The voltage of percentage 0 to 100 could be customed.
4- -: Buzzer switch and alarm value setting.11.5V-40V.
5- -: Calibrate the instrument voltage again.
5，Click the button , select the menu to enter, and hold the button for a little long time to quit.
6，All parameters must be saved at the last time.
P 2
P 3
