JLG 600 - Specifications

2008.4
1. SPECIFICATIONS(mm)
MODEL A B C D E F HOOK N.W.
JLG-600 250 160 190 35 545 87 3T 12.0KG
JLG-1T
250 160 190
35 545
87
3T 12.0KG
JLG-2T
250 160 190
40
545 87
4.5T 12.3KG
JLG-3T
250 160 190
40
545 87
4.5T 12.3KG
JLG-5T
250 160 190
50 700 89 7T 21.6KG
JLG-7.5T
250 160 190
62 700 89 8T 21.5KG
JLG-10T
250 160
240 60 790 100 11T 35.0KG
JLG-15T 250
160
250 70 1000 137 17T 45.0KG
JLG-20T 260 195 110 100 1150 120 25T 78.0KG
JLG-25T 260 195 110 100 1150 120 25T 78.0KG
JLG-30T 260 210 120 130 1300 150 35T 119KG
JLG-35T 260 210 120 130 1300 150 35T 119KG
CAPACITY DIVISION
600 KG 0.2 KG
1000 KG 0.5 KG
2000 KG 1 KG
3000 KG 1 KG
5000 KG 2 KG
7500 KG 5 KG
10000 KG 5 KG
15000 KG 10 KG
20000 KG 10 KG
25000 KG 10 KG
30000 KG 10 KG
35000 KG 10 KG
To comply with the law of certain countries, the pound unit may be disabled.
Specifications and functions subject to change without prior notice.
JLG User Manual 2
