SECTION 1 - JLG SMART SYSTEM ™ ANALYZER KIT INSTRUCTIONS (1600258 CONTROLLER).

3120442 – JLG Sizzor – 1-5

ADDITIONAL FIELD SERVICE SETTINGS

JLG STRONGLY RECOMMENDS THAT THE FOLLOWING SETTINGS NOT BE CHANGED. CHANGING THESE SETTINGS MAY ADVERSELY

AFFECT THE PERFORMANCE OF YOUR MACHINE

NOTE: 1. The steer-only-creep maximum varies, depending on the current machine model. It is not always 35%

NOTE: 2. This adjustment is only for those machines equipped with power LIFT DOWN. To identify machines equipped with

power LIFT DOWN, refer to the Effectivity Page for serial number identification.

NOTE: 3. LIFT DOWN speed is non-adjustable on machines equipped with gravity LIFT DOWN. To Identify machines equipped

with gravity LIFT DOWN, refer to the Effectivity Page for serial number identification.

Table 1-2. Additional Field Service Settings - (Machines Equipped with 1600258 controller).

PERSONALITY MIN MAX

MAX -CURRENT

0 A

200 A

ELEVATION-CUTBACK

40%

POSITRAC-TIMEOUT

0 SEC

255 SEC

HIGHDRIVE-CURRENT-LIMIT

50 A

200 A

HIGHDRIVE-TIME-LIMIT

0 SEC

25 SEC
