JLG SMART SYSTEM 2033E User Manual

SECTION 1 - JLG SMART SYSTEM ™ ANALYZER KIT INSTRUCTIONS (1600258 CONTROLLER).
1-6 – JLG Sizzor – 3120442
Table 1-3. Machine Model Default Settings Chart - (Machines equipped with 1600258 controller)
Adjustment 1532E 1932E 2033E 2046E 2646E 2658E
DRIVE ACCELERATION
1.0
1.01.01.01.01.0
DRIVE DECELERATION
0.5
0.50.50.50.50.5
LIFT ACCELERATION
1.0 1.0 1.0 1.0 1.0
1.0
LIFT DECELERATION
0.5
0.50.50.50.50.5
DECK EXT./RET. ACCELERATION
1.0 1.0 1.0 1.0 1.0 1.0
DECK EXT./RET. DECELERATION
0.5 0.5 0.5 0.5 0.5 0.5
DRIVE CREEP SPEED
8
8991010
LIFT CREEP SPEED
10
10 15 15 15 15
DECK CREEP SPEED
10 10 10 10 10 10
STEERING CREEP SPEED
20
20 20 25 25 30
STEER. DR. SPEED COMP.
20 20 20 20 20 20
DRIVE FWD & REV SPEED MAX. (EATON
DRIVE MOTORS)
80
80 100 N/A N/A N/A
(WHITE DRIVE MOTORS)
100 100 100 100 100 100
LIFT UP SPEED MAXIMUM
80-90
90
100 100 100 100
LIFT DOWN SPEED MAXIMUM*
60-70*
70-80*
80-90* 90-100* 90-100* 90-100*
DECK RETRACTION SPEED MAX.
60
60 60 60
60 60
DECK EXTENSION SPEED MAX.
100 100 100 100 100 100
ELEVATION DRIVE CUT BACK**
25**
25** 30** 30** 30** 30**
POSITRAC HOLDING TIME**
10** 10** 10** 10** 10** 10**
GROUND LIFT UP SPEED
75
75 75 80 80 90-100
GROUND LIFT DOWN SPEED*
60-70* 60-70* 60-70* 60-70* 60-70* 60-70*
GROUND DECK IN SPEED
50 50 50 50 50 50
GROUND DECK OUT SPEED
50 50 50 50
40 40
HIGH DRIVE OVERCURRENT**
165**
165** 185** 185** 185** 185**
HIGH DRIVE TIME OUT**
5.0** 5.0** 5.0** 5.0** 5.0** 5.0**
MAXIMUM CURRENT**
220** 220** 220** 220** 220** 220**
IDLE TIME OUT
10 10 10 10 10 10

JLG SMART SYSTEM 2033E Specifications

General

Gradeability	25 %
Battery Voltage	24 V
Power Source	Electric
Machine Width	1.22 m
Machine Length	2.44 m
Drive Speed - Lowered	4.8 km/h
Overall Length	2.44 m
Overall Width	1.22 m
Drive Speed	4.8 km/h
Stowed Length	2.44 m
Stowed Width	1.22 m
