1 Main frame 1 38
Screw ST4.2×20
2
2 Front stabilizer 1 39
Screw ST4.2×40
3
3 Rear stabilizer 1 40 Screw ST4.8×20 1
4L/R Swing bar 1 pr 41
Flat washer D8×3×φ38
2
5
Square end cap 2
42
Arc washerφ10×1.5×
φ25×R28
4
6L/R Pedal support 1pr 43 Bolt M8×20 2
7L/R Handlebar 1 pr 44
Hexagon bolt M10×45
4
8L/R Chain cover 1 pr 45 Nylon Nut M10 6
9 Fan wheel 1 46
Carriage bolt M10×57
4
10 Square end cap 2 47 Acorn Nut M10 4
11L/R Peddle 1pr 48L/R
Nylon nut B0.5×20
1pr
12 Handlebar shaft 1 49
Bolt ST4.8×30
4
13 End cap 4 50 Computer 1
14 Foam grip 4 51
Spring washerφ13×B2
2
15
End capφ25×2
10 52
Spring washerφ10.5×3
×φ18
2
16 Plastic bushing 4 53 Small chain wheel 1
17 Knob 4 54 Chain wheel 1
18 Plastic roller 2 55 Lock washer 1
19
Steal bushing φ24×16
×φ16.1
10 56 D-shape washer 2
20
Steal bushingφ14×10×
φ10.1
4 57 Bolt M10×18 2
21 Brass bushing 2 58 Heart rate sensor wire 2
22 Fan wheel axle 1 59 Bolt M6×45 2
23
Nut M10×1×B5
4 60 Nylon nut M6 2
24
Crankshaft M6×36
2 61
Bolt M10×55
2
25 Nut M10×1 2 62 L/R
Boltφ16×89×L23×
B0.5×20
1pr
26 Sensor wire 1 63
Round capφ32×1.5
2
27 Crank 1 64 Cap S18 2
28 Tube 2 65 Saddle 1
29 Washer 1 66 Flat washer D8 3
30L Two slot nut 1 67 Nylon nut M8 3
30R Tri-slot nut 1 68 Saddle post
1
31 Collar ball 2 69 Saddle post tube 1
32 Shaft bowl 2 70 Knob 1
33 Screw 1
71 Cap S13 4
34 Chain belt 1
72 Front support 1
35 Tension belt 1
73 Washer 1
36 Tension control 1
74 Cap S16 4
37 Sensor connecting wire 1
