81900523 Rev. A
©2021 JMA Wireless. All rights reserved. This document contains proprietary information. All products, company names, brands, and logos are trademarks™ or
registered® trademarks of their respective holders. All specifications are subject to change without notice. Revised: November 12, 2021
+1 315.431.7100 customerservice@jmawireless.com
Installation Guide
MX/MC Model Brackets
Instructions for extension kit for MX08FIT265-01
Kit #91900330: MX08FIT265-01 extension
bracket kit
Item
#
Part # Description Qty.
in kit
1 45700384-01 Back grip bracket 2
2 34200019-04 3/8” lock washer, HDG 29
3 45700382-01 Single mount adapter 2
4 45700391-01
Negative degree adj. bottom
bracket
2
5 45700385-01 Anti-rotation bracket 2
6 41100318-01 Threaded rod 4
7 34200035-01 3/8” bolt, HDG 21
8 45700380-01
Antenna linkage arm
mounting bracket
2
9 45700563-02
MX08 extension bracket,
long
4
10 45700381-01
Tilt select arm mounting
bracket
2
11 34200018-05 3/8” flat washer, HDG 54
12 34200017-09 3/8” hex nut, galv. 33
13 45700563-01
MX08 extension bracket,
short
4
NOTE: These item numbers refer to Figures 4 and 5 on pages 6
and 7. Item 9 is interchangeable with Item 13, depending on
the length of the bracket you wish to use.
Other key details:
▪ The brackets were designed to handle pole diameters ranging from
2.5 to 4.5 inches.
▪ When tightening all hardware, use the torque setting 20 lbf·ft.
This is the installation guide for the extension kit for the
MX08FIT265-01 antenna. This kit allows the antenna to be
either in-line or above the other macro antennas mounted
adjacent to it, which helps to avoid pattern interference.
Below is the bracket kit included with the antenna.
2 3
