POWER SC2
POWER SELECTION
JOEMEEK Compressors VER 1.07 and later, are fitted with a mains
voltage selector for easy change of input voltage.
The fuse carriage can be pulled out and rotated to select to the local
power voltage.
In the '110' position, the unit will operate between 95 and 125V AC.
In the '230' position, the unit will operate between 210 and 240V AC.
The fuse can remain at 500mA for both ranges.
POWER EARTH (GROUND) CONNECTION
The center (ground) pin of the IEC power connector is connected to
the steel chassis of the compressor. The Audio ground is not
connected to chassis.
The power system is double insulated throughout so that power
ground may be lifted off if required without affecting safety in any
way.
Page 8
