Figure 12
A s sembl y
IM-459000
8
9. HPL402 only - Raise boom to highest position;
pull vinyl boot over bolted connection (Fig. 9,10).
10.
Attach adjusting lever handle into base (Fig. 11).
11 .
Wheel locks are provided for parking. To lock
casters, step on cam lever on side of casters. To
unlock, step on highest cam lever (Fig. 12).
Never lock wheel locks or block wheels when
lifting someone. Wheel locks are provided for
parking the lifter only.
BE SURE TO READ THE SEPARATE MANUAL
“HOW TO USE A PATIENT LIFTER” BEFORE
ATTEMPTING A LIFT.
Figure 10
Figure 9
Figure 11
