John Lewis Mixit - Page 2

Metal dowel x 24 Long cam lock x 8 Wooden dowel x 24
30mm
Short cam lock x 16 30mm Screw x 16 Support foot x 4
Strap x 1 11mm Euroscrew x 16 15mm Screw x 25
25mm Nail x 30 Bumper x 8 Levelling Wedge x 2
Fixing block x 8
27mm Connector x 4 4MAx15 Connect. screw x 4
Pair of rollers 4
A B
C
G
L
H
M
D E
F
I
N
O P Q
Z2
Z1
Nail guide x 1
P1
Page 2
MXT 04/13
Fittings checklist
