Z370584 Rev. D Bluetooth Characteristics
12-17
Bluetooth Characteristics
Table 12.12 – RF Receive Section
Parameter Test Conditions Min
Typ
Max Unit
Receiver sensitivity
(2)
High-gain mode -93 dBM
Receiver sensitivity
(2)
Standard mode -87 dBM
Saturation
(3)
6dBM
Co-channel rejection
(3)
-5 dB
Adjacent-channel rejection
(3)
±1 MHz -5 dB
Alternate-channel rejection
(3)
±2 MHz 30 dB
Blocking
(3)
-30 dBM
Frequency error tolerance
(4)
Including both initial tolerance
and drift
-250 250 kHz
Symbol rate error tolerance
(5)
-80 80 Ppm
Spurious emission. Only
largest spurious emission
stated within each band.
Conducted measurement with a
50-Ω single-ended load.
Complies with EN 300 328, EN
300 440 class 2, FCC CFR47, Part
15 and ARIB STD-T-66
-75
dBm
Current consumption RX mode, standard mode, no
peripherals active, low MCU
activity, MCU at 250 kHz
19.6
mA
RX mode, high-gain mode, no
peripherals active, low MCU
activity, MCU at 250 kHz
22.1
(1) 0.1% BER maps to 30.8% PER
(2) The receiver sensitivity setting is programmable using a TI BLE stack vendor-specific API command.
The default value is standard mode.
(3) Results based on standard gain mode.
(4) Difference between center frequency of the received RF signal and local oscillator frequency
(5) Difference between incoming symbol rate and the internally generated symbol rate
