Air Dryers—A-4400 Series Technical Bulletin 27
Table 3: Repair Parts
Item
Description
Shipping
Weight
lb*
CodeNumber
Date Codes
through RY1
9923
Date Codes
after RY1 9923
Date Codes
after RY1
1351
A
System Pressure Gauge
0.1
G-2010-5
B
Evaporator Pressure Gauge
0.2
A-4300-603
C
Pressure Reducing Valve
1.7
R-130-14
D
Service Bypass Valve
0.4
A-4300-600
E
Condensate Filter:
Complete Assembly
1.1
A-4000-158**
A-4000-156
Bowl O-Ring
0.02
A-4110-610
A-4400-610
Replacement Drain Valve
0.1
A-4110-607
A-4400-607
Particle Filter Element
0.05
A-4110-608
A-4400-608
F
Coalescing Filter:
Complete Assembly for
Air Dryer Model
A-4412
2.0
A-4000-1048
A-4417 and A-4423
2.5
A-4000-1049
Filter Element with O-Rings:
Air Dryer Model
A-4412
0.1
A-4110-604
A-4417 and A-4423
0.1
A-4000-604
Universal O-Ring Kit for Filter
Element Bowl
0.03 A-4000-620
Replacement Drain Valve***
0.2
A-4000-6010****
Manual Override for Drain
Valve
.25 A-4000-1054****
G
Carbon Filter Element Only:
Air Dryer Model
A-4412
1.7
A-4000-632
A-4417 and A-4423
3.8
A-4000-633
H
Safety Relief Valve
0.1
A-4000-144
J
Condenser Fan Motor
2.2
A-4300-601
K
Power On/Fail Lamp
0.05
A-4300-602
L
Insulating Tape (Not Shown)
(Order in multiples of 30 ft)
1.2
A-4210-603
M
Start Relay (Tecumseh P/N)
--
P82928
820-10052
Overload Relay
(Tecumseh P/N)
--
P83458 830-10041
* lb x 0.454 = kg.
** Includes A-4000-156 filter, new mounting bracket, mounting hardware, tubing, and drain pipe adapter.
*** The A-4000-6010 replacement drain valve does not include a bowl-to-body O-ring. If this O-ring is needed,
order the A-4000-620 Kit separately.
An F-400-20 Coupling (1/8 in. external NPT x 1/8 in. internal NPT) is included with the replacement drain valve.
**** The A-4000-6010 auto drain and A-4000-1054 manual override assemblies are only compatible with each other
and do not work with the A-4000-610 auto drain and A-4000-154 manual override assemblies.
