Accessories
Table 9: Controller accessories (order separately)
Product code number Description
IOM Series Controllers
Refer to the Metasys
®
System Field Equipment Controllers and Related Products Product Bulletin
(LIT-12011042) for a complete list of available IOM Series Controllers.
Mobile Access Portal (MAP) Gateway
Refer to the Mobile Access Portal Gateway Catalog Page (LIT-1900869) to identify the
appropriate product for your region.
Note: The MAP Gateway serves as a replacement for the BTCVT, which is no longer
available for purchase, but continues to be supported.
TL-CCT-0 Metasys Controller Configuration Tool
MS-FCP-0 Metasys Equipment Controller Firmware Package Files for CCT
WRZ Series Sensors
Refer to the WRZ Series Wireless Room Sensors Product Bulletin (LIT-12011653) for a complete
list of available WRZ Series Sensors.
MS-DIS1710-0 Local Controller Display
Y64T15-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 92 VA, Foot Mount, 72.2 cm (30
in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65A13-0
Transformer, 120 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AS), 20.32 cm (8
in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65T42-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Hub Mount (Y65SP+),
20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
Y65T31-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AR+),
20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
AP-TBK1002-0 2-position Screw Terminal that plugs onto VMA Output Point Spade Lugs
AP-TBK1003-0 3-position Screw Terminal that plugs onto VMA Output Point Spade Lugs
AP-TBK4SA-0 Replacement MS/TP SA Bus Terminal, 4-Position Connector, Brown, Bulk Pack of 10
AP-TBK2PW-0 Replacement Power Terminal, 2-Position Connector, Gray, Bulk Pack of 10
MS-VMAACT-701 VMA Actuator Assembly Gearbox Replacement Kit
AS-CBLTSTAT-0 Cable adapter for connection to 8-pin TE-6700 Series sensors
F-1000-325
Replacement Barbed Fitting for use on VMA1615, VMA1630, and VMA1832 for Connecting
Tubing, Bulk Pack of 10
F-1000-326
Flexible Tubing Extension with Barbed Fitting for VMA1615, VMA1630, and VMA1832, 35.56
cm (14 in.) Length, Bulk Pack of 20
TL-BRTRP-0 Portable BACnet/IP to MS/TP Router
VMA1615/1626/1628/1630 VAV Controllers Installation Guide20
