©2017 Johnson Level & Tool 7
Using the Product in Self-Leveling Mode
Slide the locking compensator up to the unlocked position to power
on the unit. The status light will illuminate, and the unit will emit
two laser beams.
Slide the locking compensator down to the unlocked position to
power off the unit.
Note: The 3-Dot Laser must be within ±4° of level for the self-
leveling feature to function properly. If the instrument is beyond its
4° self-leveling range, the laser will not self-level, the laser will flash
and the status light will turn red. Once the instrument has been
adjusted to within its 4° self-leveling range, the laser will self-level,
the status light will turn green and the laser light will stop flashing
and remain solid.
Using the Product in Tilt (Manual Level) Mode
The Self-Leveling Cross-Line Laser can be used to project laser
beams at any angle desired, such as when projecting a line for stairs
or a railing. This mode produces the best results when the tool is
mounted on a tripod.
With the locking compensator down in the locked position, press the
tilt mode button to power on the unit. The status light will illuminate
in red to indicate that the tool is not self-leveling, and the unit will
emit two laser beams. The lasers will be perpendicular to each other,
but will not self level.
Press the tilt mode button to power off the unit.
1834i-English_Manuals 4/27/17 2:22 PM Page 7
