Johnson Pump L550 - English

6
English
• Mount in the lowest
point of the bilge
• For longer pump life,
do not run dry
Lowest level for suction
Measure "A"
L450 – 8 mm
L550 – 8 mm
L650 – 8 mm
L750 – 8 mm
Type designation
Pump type L450 – 12 V L550 – 12 V L650 – 12 V L750 – 12 V
Art no 32-1450-01 32-1550-01 32-1650-01 32-1750-01
A
Design features
L450 L550 L650 L750
Hose size 3/4" 3/4" 3/4" 1.1/8"
Capacity, straight (13.6 V) 49 l/min/778 GPH 56 l/min/884 GPH 61 l/min/972 GPH 73 l/min /1,150 GPH
Capacity, 1 m head (13.6 V) 38 l/min/601 GPH 45 l/min/713 GPH 53 l/min/844 GPH 60 l/min /952 GPH
Voltage 12 V DC 12 V DC 12 V DC 12 V DC
Amperage 2,5 A 3 A 3.2 A 3 A
Fuse size 3 A 5 A 5 A 5 A
Height 112 mm 112 mm 112 mm 112 mm
Max dia 70 mm 70 mm 70 mm 70 mm
Weight 0.27 kg 0.27 kg 0.27 kg 0.32 kg
Body Thermoplastic Thermoplastic Thermoplastic Thermoplastic
Shaft seal Lip seal Lip seal Lip seal Lip seal
Wire size 0.75 mm
2
0.75 mm
2
0.75 mm
2
0.75 mm
2
