Positioning The Appliance
Position the appliance in the desired location. The back should rest
against the wall behind it, and the sides, along the adjacent cabinets or
walls. The dishwasher is equipped with water supply and drain hoses
that can be positioned either to the right or the left sides to facilitate
proper installation.
Step 1. Selecting the best location for the dishwasher
The installation position of the dishwasher should be near the existing
inlet and drain hose and power cord. Illustrations of cabinet dimensions
and installation position of the dishwasher.
1. Less than 5 mm between the top of dishwasher and cabinet and the
outer door aligned to cabinet.
90 °
90 °
580580mm
00820mm
100
880
Built-In Installation(for the integrated model
Electrical, drain
and water supply
line connection
Space between
cabinet bottom
and floor
600 mm (for 60cm model)
450 mm (for 45 cm model)
