REPLACEMENT OF ROTATING HEADS
Replace the 3 heads every 1 - 2 years de-
pending on use or if damaged, for always
optimal shaving performance.
Make sure that the appliance is turned off
and unplugged from the power socket.
Extract the sheet assembly with the 3 rota-
ting heads (F) from the body of the device
(see accessories removal paragraph).
Press the button (T) and open the foil
unit (F) as shown. Turn the knob (U) an-
ticlockwise until the sealing support (V) is
released and remove the 3 worn or dama-
ged rotating heads and replace them with
3 new rotating heads.
ATTENTION: the heads must be inserted
correctly making the notch (Z) of the head
coincide with the tab (W) on the head sup-
port.
After having correctly inserted all 3 ro-
tating heads, also reposition the tenu-ta
support (V) correctly and lock it by turning
the knob (U) clockwise as shown.
Close the sheet assembly (F) and put it
back on the appliance body (see accesso-
ries assembly paragraph).
(see fig. 21-22-23-24)
Technical features:
Technical features:
5V d.c. 5W IPX6
Batteriy:
Li-ion 3,7V d.c. 800 mA
AAdapter mod. KH6-050100EU
input100-240V~ 50/60Hz 0,2A max
Output:
5V d.c. 1000 mA
Demonstration movie
Video dimostrativo
