OG1:3
RT655 Operator’s Guide
Johnston Sweepers Limited
Chapter - General Arrangement
Page Issue A
Item Component See Chapter
1 Hopper/load compartment -
2 Auxiliary engine cowl -
3 Body (hopper and cowl) prop 3
4 Auxiliary engine 6
5 Fuel tank -
6 Fuel tank filler access flap -
7 Hydraulic oil reservoir 6
8 Suction fan case 6
9 Variable exhaust gate (VEG) -
10 Pick-up head (hood) 6
11 Blaster duct -
12 Suction duct -
13 Channel brush / gutter broom 6
14 Wear plate -
15 Filter screen 6
16 Filter screen curtain 6
17 Filter screen water sprays 6
18 ‘SepaVac’ separator box 3
19 ‘SepaVac’ access panel -
20 ‘SepaVac’ discharge door 3
21 ‘SepaVac’ water flush 3
22 ‘SepaVac’ water flush hydrant connection 3
23 * R.H. Water tank and contents gauge 6
24 * L.H. Water tank, contents gauge and hose filler 6
25 Water tank(s) hydrant filler 6
26 Water tank drain tap - under both tanks 6
27 Water pump suction filter 6
28 Rear door drainage hoses 3
29 Rear door access door 3
30 Low pressure water spray jets -
31 High pressure Water spray jets -
32 Washdown hose -
33 Master control panel 2
34 Air cleaner 6
35 Air cleaner filter state indicator 6
36 Hydrant hose stowage - optional -
37 Supawash hose reel & handlance 4
* Total water capacity 950 litres
