Joie elevate User Manual

7 8
see images
1
-
10
! Must open the side impact shield plastic to protect the child
more safely.
! Make sure that no part of the seat covering interferes when
attaching backrest to the base.
1
2
Booster Assembly
3
4
5
6
7
8
10
9
Height Adjustment – for Head Support
see images
11
1. Please adjust the head support
to proper height according to
the child's height.
2. Squeeze the head support
adjustment lever, meanwhile
pull up or push down the head
support until it snaps into one
of the 10 positions.
! Before adjusting the head
support height have your child
lean forward slightly.
11

Joie elevate Specifications

General

Headrest	Yes
Mounting type	-
Product color	Black
Car seat group	0+/1/2/3 (0 - 36kg; 0 months - 12 years)
Belt fastening type	5-point
Maximum weight capacity	36 kg

Weight and Dimensions

Depth	500 mm
Width	508 mm
Height	830 mm
Weight	5470 g
