13 14
! The ISOFIX connectors must be
attached and locked onto the
ISOFIX anchor points.
23
-1
! The load leg must be installed
correctly with green indicator.
23
-2
! Always make sure the seat is in
locked position (rearward facing /
forward facing) even when the
child is not in it.
Securing Child
After the child is placed into the
seat, check whether the Shoulder
Harness Straps are at proper height.
1. Press the webbing adjustment
button, while pulling out the
shoulder harnesses to the proper
length.
24
2. Unlock the buckle of the
harnesses by pressing the red
button.
25
24
23
2
1
25
3. Fix the buckles on the both sides
of seat to make placing the child
in rear facing mode more
convenient.
26
4. Use infant insert is for children’s
protection.
27
27
26
We recommend using the full infant insert while the baby is under
60cm and can be used until they outgrow the infant insert. The infant
insert increases side impact protection.
