11 12
Height Adjustment
for Head Support and Shoulder Harnesses
see images
17
-
19
1. Please adjust the head support
and check if the shoulder
harnesses are at the correct
height according to
17
! When used rear facing, the
shoulder harness height must be
even with child’s shoulders.
17
! When used forward facing, the
shoulder harness height must be
even with child’s shoulders.
17
2. Lift up the head support
adjustment lever
18
, meanwhile
pull up or push down on the head
support until it snaps into one of
the 6 positions. The head support
positions are shown as
19
.
17
18
19
Using in the Rear Facing Mode
(Child height 40cm-105cm/Child weight 19.5kg/
infant - 4 years old)
see images
3
-
9
! Please install the child restraint on
the rear vehicle seat, and then put
the child in the child restraint.
see images
20
-
29
1. Press the ISOFIX adjuster button
20
-1 and pull the base back from
the vehicle seat.
2. Press the rotating button to rotate
for easier side loading/unloading
of the child, then rotate back to
desired direction.
21
&
23
3. If a tighter install or increased
cabin space is required, then
press the ISOFIX adjuster button
22
-1 and push to adjust.
22
-2
20
1
2
21
22
1
2
