17 18
Using in the Rear Facing Mode
(Child height 61cm-105cm/ Child weight
19kg/ 6 months - 4 years old)
see images
20
-
29
! Please install the enhanced child
restraint on the rear vehicle seat
and then put the child in the
enhanced child restraint.
1. Press the ISOFIX adjuster button
20
-1 and pull the base back from
the vehicle seat.
2. Press the rotating button to rotate
for easier side loading/unloading
of the child, then rotate the seat
to the rear facing position.
21
&
22
! Press the rotating button on either
side to rotate the enhanced child
restraint.
20
1
2
3. After successfully installing the
ISOFIX connectors, press the
ISOFIX adjustment buttons again
while pushing the seat back until
it comes in contact with the
vehicle seat back.
23
-1
23
-2
! The ISOFIX connectors must be
attached and locked onto the
ISOFIX anchor points.
24
-1
! The load leg must be installed
correctly with green indicator.
24
-2
23
1
2
22
21
24
2
1
