Joie i-Spin 360 E - Using in the Forward Facing Mode

21 22
see images
30
-
38
! Please install the enhanced child
restraint on the vehicle seat, and
then put the child in the enhanced
child restraint.
1. Press the ISOFIX adjuster button
30
-1 and pull the base back from
the vehicle seat.
30
-2
Using in the Forward Facing Mode
(Child height 76cm-105cm/ Child weight
19kg/ 15 months - 4 years old)
2. Press the rotating button to rotate
for easier side loading/unloading
of the child, then rotate the seat
to the forward facing position.
31
&
32
! Press the rotating button on either
side to rotate the enhanced child
restraint.
3. After successfully installing the
ISOFIX connectors, press the
ISOFIX adjustment buttons again
while pushing the seat back until
it comes in contact with the
vehicle seat back.
33
-1
33
-2
30
1
2
32
31
1
2
33
