Use Tray Cover and Tray Insert
1. To attach the tray cover, place it over the tray and push down until tab snaps into place.
21
22
2. To remove the tray cover, grasp the tab near the seating area and pull up, then lift the tray cover
upwards.
23
Adjust Height for Seat
1. There are 7 height positions. The seat can be adjusted to the proper height according to the height of
your dinner table, which makes it more convenient for your child to have meals together with family.
! DO NOT adjust the height of the seat with child in it.
2. To adjust height, squeeze the height adjustment buttons on both sides of the chair
24
- 1, and lower
or raise seat to a desired position.
24
- 2
Adjust Recline
! DO NOT adjust the seat recline with child in it.
1. There are 3 recline positions.
2. Squeeze button on the back of seat
25
- 1 and push down or pull up
25
- 2 to adjust the seat back to
a desired recline position.
Fold Highchair
! DO NOT fold the highchair with child in it.
Fold the highchair by following these steps:
1. Remove tray before folding the highchair.
2 For most compact storage, lower the seat to the lowest position and adjust the calf support to
horizontal or flat position.
26
3. Fold the seat.
27
4. Fold the frame.
28
5. Store the tray on the rear legs.
29
Release Buckle
Press the center button to release the buckles.
11
Adjust Height for Shoulder Harnesses
1. Choose a pair of proper shoulder slots. Insert the shoulder harnesses into slots in seat pad and seat
back.
12
13
! When changing shoulder harness slots, make sure shoulder harnesses are going through
same slots in seat pad and seat back.
Adjust Length for Harnesses
1. Use slide adjuster to change the harness length.
14
- 1
2. Pull waist harness to tighten to proper length
14
- 2. Press the button to loosen the waist harness.
14
- 3
Use Tray
Assemble Tray
1. Fit the crotch restraint and tray mount onto the tray by pushing into the opening on the tray bottom
until you hear a "click" sound.
15
16
! Both the crotch restraint and tray mount can only be assembled in one direction. The slots on the
crotch restraint and tray mount attachment should be aligned with the ribs in the opening of the tray
bottom.
2. Insert the tray guides into the holes in the seat, slide forward until a “click” is heard.
17
To remove
tray, squeeze the button under the tray and slide off.
18
! The tray horn must be inserted into tray before use. Once the tray horn is inserted, do not attempt
to remove it.
! Use caution when adjusting tray, as the tray can be completely removed from the seat.
Tray Adjustment
1. The tray has 3 positions. The distance between your child and tray can be adjusted as needed.
2. Squeeze the button under the tray and move the tray until a desired position is reached, and then
release the button. If the tray is not automatically locked in the holes, move the tray until a “click” is
heard.
19
! Ensure both sides of tray are in matching positions.
! Pull the tray towards you to ensure both guides are secure.
Tray Storage
1. When the tray is not in use, It can be stored on the rear legs.
2. Place the tray over the rear legs and snap the tray guides into place.
20
3. The stored tray is shown in
20
.
Note
1. The shoulder harness must go into the slot that is even with or slightly above the shoulders.
2. In order to protect your child from falling out, after your child is placed into the seat, check whether the
shoulder harnesses are at proper height.
3. For larger child, use the upper shoulder slots. For smaller child, use the lower shoulder slots.
Note
1. The tray cover or tray insert can be used together with the tray. They can also remain attached when
the tray is stored.
2. When placed on the dinner table, the tray cover and tray insert can be used as serving trays.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Joie Mimzy and is the answer not in the manual?

Joie Mimzy Specifications

General IconGeneral
Usage Age6 months to 3 years
Weight Limit15 kg
Recline Positions3
Tray Adjustments3
Adjustable HeightYes
Reclining SeatYes
Removable TrayYes
FoldableYes
WheelsYes
Safety Harness5-point
MaterialPlastic
