Joie Stages User Manual

9 10
3
2
1
4
5
The recline positions are shown in
5
.
There are three recline positions (1-3) for
forward-facing Toddler mode and two recline
positions (1-2) for forward-facing Youth mode
5
.
The recline position 4 is for rearward-facing Infant
mode
5
.
Angle indication: with top and bottom triangles
aligned
5
.
Please adjust the head support and shoulder harness straps to the proper height according to the child's
height.
! When used in rearward-facing Infant mode﹐ the shoulder harness slots must be even with or just below the
child's shoulders.
6
- 1
! When used in forward-facing Toddler mode﹐ the shoulder harness slots must be even with or just above the
child’s shoulders.
6
- 2
! When used in forward-facing Youth mode﹐ the shoulder belt guides must be even with or just above the
child’s shoulders.
6
- 3
If the shoulder harness straps are not at proper height﹐ the child may be ejected from the child restraint during
a crash.
Reference age Newborn -4 year old
Seat position Position 4 (with top triangle and blue triangle aligned﹐ as shown in
5
).
! Please install the child restraint on the vehicle seat first﹐ and then place the child in the child restraint.
i. Installation for Rearward-Facing Infant Mode
Height Adjustment
(for Head Support and Shoulder Harness Straps)
Height Adjustment
(for Head Support and Shoulder Harness Straps)
Infant Mode
(for Child under 18kg / Newborn -4 year old)
6
1
2
3
see images
6
-
7
7
1
Squeeze the head support adjustment handle
7
- 1 and pull up or push down the head support
until it snaps into one of the five positions.
The head support positions are shown in
7
.
see images
8
-
22
1. First adjust the child restraint to recline Position 4. Angle indication: With top triangle and blue triangle
aligned
5
. Please refer to image 4 (Reclining Adjustment).
2. Make sure the shoulder harness straps are adjusted to the proper height before installing this child
restraint. Please refer to images 6-7 (Height Adjustment for Head Support and Shoulder Harness Straps).
3. When installing and adjusting the vehicle belts, make sure that both the vehicle shoulder belt and the
vehicle waist belt are not twisted or the belts may not function properly.
Note
see images
8
-
16

Joie Stages Specifications

General

Weight range	0-25 kg
Harness type	5-point harness
Group	0+/1/2
Side Impact Protection	Yes
Weight	8.86 kg
Isofix	No
Washable Cover	Yes
Compatibility	Universal
Age range	Birth to approx. 7 years
Installation	3-point car seat belt
Rearward facing	Up to 18 kg
Forward facing	9-25 kg
Recline positions	4 recline positions
Headrest	Adjustable headrest
