Joie traver User Manual

9 10
2. Press the Isosafe adjusting
button to pull out the Isosafe
connectors.
11
Rotate the Isosafe connectors 180
degrees until they are pointing in
the direction of the ISOFIX guides.
12
11
2
2
1
1
12
3. Line up the Isosafe connectors
with the ISOFIX anchor points,
and then click both Isosafe
connectors into the ISOFIX
anchor points.
13
! Make sure that both Isosafe
connectors are securely
attached to their ISOFIX
anchor points. The colors of
the indicators on the both
Isosafe connectors should be
completely green.
13
-1
! Check to make sure the
booster is securely installed
by pulling on the both Isosafe
connectors.
4. To remove the booster:
a. Press the secondary lock
button
14
-1 first and then the
button
14
-2 on the Isosafe
connectors before removing
the booster from the vehicle
seat.
b. Rotate the Isosafe
connectors by 180 degrees,
then press the Isosafe
adjusting button to fold the
Isosafe connectors.
15
1
13
14
1
2

Joie traver Specifications

General

Headrest	Yes
Coloration	Monochromatic
Product type	High-back car booster seat
Washing type	Machine wash
Mounting type	ISOFIX + Seat belt
Product color	Gray
Maximum weight	36 kg
Minimum weight	9 kg
Suggested gender	Boy/Girl
Recommended age (max)	12 yr(s)
Recommended age (min)	1 yr(s)
Car booster seat group	-

Weight and Dimensions

Depth	409 mm
Width	555 mm
Weight	6970 g
Height (max)	854 mm
