SAFETY - READ ALL INSTRUCTIONS
The following are important safety instructions for using the JOINTECH Saw Train.
Before using Saw Train, read and follow all of the instructions and safety information in this manual.
• When using the Saw Train in conjunction with
any other tool, first read and follow all
instructions and safety information in that
tool’s owner’s manual.
• Never let any part of the Saw Train interfere
with another tool’s safety guards or other
safety equipment.
• Before using your Saw Train, make sure all
mounting screws are tight and that the bridge-
clamping knob is securely tightened against
rail.
• Always turn off the power to saw or router
prior to any adjustment of Saw Train. Allow a
cutting tool to come to a complete stop before
repositioning of fence.
• Always keep both hands behind fence when
moving fence to a new setting.
• Before making a cut always make sure that
the bridge clamp is securely tightened against
rail and fence machine is securely locked in
position.
• Use appropriate safety devices. Keep hands
clear of saw blade or router bit! Always use a
push stick, rubber-soled push block, or other
safety devices to keep your hands safely
away from cutter.
• Never let the saw blade or router cutter come
into contact with any part of Saw Train or
fence machine.
• Wear safety glasses, hearing protection, and
follow all normal shop safety practices.
• Never operate your table saw without a blade
guard.
FASTENERS
EXTENSION TABLE MOUNTING HARDWARE PACK RAIL MOUNTING HARDWARE PACK
(Packed with rails) (Packed with Bridge assembly)
Description
Angle bracket
¼-20 x ½” machine screw
¼-20 heavy hex nut
¼” flat washer
#14 x 1” lag screw
JST-4
4 ea.
4 ea.
4 ea.
4 ea.
4 ea.
JST-6 & 56
6 ea.
6 ea.
6 ea.
6 ea.
6 ea.
JST-8
10 ea.
10 ea.
10 ea.
10 ea.
10 ea.
Description
5/16-18 x 1” carriage bolt
5/16-18 keps nut
Rectangular stamped washer
Bridge stop (assembled)
Rail end cover plate
#8 x ½” hex head screw
UHMW tape, 1-1/2” x 2”
6 ea.
6 ea.
6 ea.
1 ea.
4 ea.
8 ea.
1 ea
-2-
