Jonsered B 2126 - Technical Data

English--- 19
545154659 Rev. 10 3/15/12
TECHNICAL DATA
Fan B2126 BV2126
Type Radial fan Radial fan
M ax. air velo cit y, m/ s (km/ h), standa rd nozzle 60 (217) 60 (217)
Max. air velocity, m/s (km/h), high velocity
nozzle* 76 (273) 76 (273)
Air volume -- blowing, m
3
/h (cfm) 722 (425) 722 (425)
Air volume -- vacuuming, m
3
/h (cfm) ---- 756 (445)
*optional accessory for some models
Technical data
B2126 BV2126
Engine
Cylinder volume, cu.in./cm
3
1.7/28 1.7/28
Cylinder bore, inch/mm 1.4/35 1.4/35
Stroke, inch/mm 1.130/28.7 1.130/28.7
Idle speed, rpm 2,800--3,200 2,800--3,200
Max. speed - blowing, rpm: 8,600 8,600
Max. speed - vacuuming, rpm: ---- 7,500
Max. engine output, acc. to ISO 8893,
hp/kW 1.1/0.8 1.1/0.8
Catalytic converter muffler Yes Ye s
Speed--regulated ignition system No No
Ignition system
Manufacturer/type of ignition system Phelon/CD Phelon/CD
Spark plug Champion Champion
RCJ--6Y RCJ--6Y
Electrode gap, inch/mm 0.024/0.6 0.024/0.6
Fuel and lubrication system
Manufacturer/type of carburetor Zama Zama
Fuel tank capacity, US pint/liter 1.05/0.5 1.05/0.5
Weight
Weight, without fuel but with blower tube
and standard nozzle fitted, lbs/kg 9.4/4.3 9.6/4.4
Sound levels
Equivalent sound pressure level, measured
according to ANSI B175.2--2000, dB(A) 70 71
Vibration levels
Vibration levels at handles, measured
according to ANSI B175.3--1997, m/s
2
At idle: 5.0 5.0
At max. speed: 11.8 11.8
NOTE! This spark ignition system complies with the Canadian standard ICES--002.
