English---10
115278026 Rev. 2 5/1/10
DESCRIPTION
Adjusting the carburetor
NOTFORALLMODELS
S There are three adjusting screws (R) for
adjusting the carburetor:
S Low speed jet
S High speed jet
S Adjustment screw for idling
S Adjusting the carburetor involves adapt-
ing the engine to local operating condi-
tions, e.g. climate, altitude, gasoline and
type of two--stroke engine oil used. For
details about carburetor adjustment, see
the Maintenance section.
R
Choke
S The choke (Q) is located below the air
filter cover and should be used every
time the engine is cold--started.
Q
