Jonsered CS 2260 - Throttle lockout and chain catcher; Right hand guard and vibration damping

10 - English
Displacement Cylinder diameter Stroke length Max. output/speed
cm3/cubic inch Ø mm/Ø inch mm/inch kW/hp/ rpm
CS 2258: 59,8 / 3.65 46 / 1.81 36 / 1.42 3.1 / 4,2 / 9 600
CS 2260: 59,8 / 3.65 46 / 1.81 36 / 1.42 3.5 / 4,8 / 9 600
CS 2260WH: 59,8 / 3.65 46 / 1.81 36 / 1.42 3.5 / 4,8 / 9 600
Electrode gap Ignition system Air gap
mm/inch mm/inch
CS 2258: 0,5 / 0.02 SEM-DM61 0,3 / 0.012
CS 2260: 0,5 / 0.02 SEM-DM61 0,3 / 0.012
CS 2260WH: 0,5 / 0.02 SEM-DM61 0,3 / 0.012
Usable cutting length Chain speed att 133% of Chain pitch Drive link
cm/inch maximum engine power speed mm/inch mm/inch
ft/s / m/s
CS 2258: 31-58 / 12-23 92.8 /
28,3 8,25 / 0.325 9,52 / 3/8 1,3 / 0.050 - 1,5 / 0.058
CS 2260: 31-58 / 12-23 92.8 / 28,3 8,25 / 0.325 9,52 / 3/8 1,3 / 0.050 - 1,5 / 0.058
CS 2260WH: 31-58 / 12-23 92.8 / 28,3 8,25 / 0.325 9,52 / 3/8 1,3 / 0.050 - 1,5 / 0.058
3 Technical data
Technical data
