PARAMOUNT PARTS LIST
R
WEED EATER PARTS LIST
R
R
POULAN PARTS LIST
R
PARTS LIST
Note:
Illustration may differ from actual model due to design changes
PARTS LIST NO.
PAGE NO.
MODEL(s)
530084491
GT26L
DATE
7/24/02
5
REPLACES
530084491--12/05/01
1. 530069829 Carburetor Repair Kit
(KIT= Indicates Contents)
2. 530038478 Limiter Cap--Low (tan)
3. 530038479 Limiter Cap--High
(brown)
4. 530069844 Gasket/Diaphragm Kit
(
D
Indicates Contents)
1
Ref. Part No. Description
=
NEW PART NUMBER FOR THIS IPL
n
=
REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
D
K
Carb.
Repair
Kit
Carburetor Assembly -- #530069902 WT--380
=
THESE PARTS ARE ILLUSTRATED FOR CLARITY. ORDER COMPLETE ASSEMBLY.
2
3
KIT
KIT
D
KIT
D
KIT
D
KIT
D
KIT
KIT
KIT
4
Gasket/
Diaphragm
Kit
Service Reference
KK KKK KK KKK
This unit was built with two different style gearboxes and driveshaft housings. When
ordering these parts, please identify the type you have and order accordingly.
Drive Shaft Housing
(Gearbox end)
Previous Style
Drive Shaft Housing
(Gearbox end)
New Style
530095409 Assy--Gearbox
530071407 Housing -- Driveshaft
530094566 Shaft--Flex
530095449 Cup--Dust
Part No.
Description
530071375 Assy--Gearbox
530071288 Housing -- Driveshaft
530095795 Shaft--Flex
530095814 Cup--Dust
Part No.
Description
