Jonsered LT2122A2 Spare Parts Manual

1 532 18 88-76 Decal Hood Side Panel
2 532 14 08-37 Decal, Brake Parking Sandle
3 532 18 95-53 Decal, Hood RH/LH
4 532 18 91-54 Decal, Replacement
5 532 16 03-96 Decal, V-Belt Sch.
6 532 19 63-57 Decal, Defl . Warn. Cutfi nger
7 532 18 21-66 Decal, Mower Cutfi nger Symbol
8 532 18 39-30 Decal, Logo, Fender
9 532 18 04-32 Decal, 100 DB/CE
10 532 40 03-89 Decal, Warning Symbols CE
11 532 14 50-05 Decal, Bat Dan/Poi P/L Sym
12 532 40 17-47 Decal, Fender
13 532 40 11-46 Decal, Warning Service/Fire
14 532 19 68-41 Decal, Warning Eng. Syms.
15 532 18 57-73 Decal, Logo Steering Wheel Cap
16 532 15 97-36 Decal, Chassis Hot Muffl er
17 532 15 97-37 Decal, Brake/Clutch Symbol LT
18 532 17 83-02 Decal, Oper. Cruise Sym.
- - 532 16 25-98 Decal, Drawbar Load Limit
- - 532 16 69-60 Decal, By-Pass Lt Hydro
- - 532 19 17-87 Pad, Footrest LH
- - 532 19 17-86 Pad, Footrest RH
- - 532 40 09-55 Manual, Operator's (Euro)
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
5
8
15
9
2
7
WHEELS & TIRES
1 532 05 91-92 Cap Valve Tire
2 532 06 51-39 Stem Valve
3 532 10 62-22 Tire F Ts 15 x 6 0 - 6 Service
4 532 05 99-04 Tube Front (Service Item Only)
5 532 13 83-36 Rim Asm 6"front Service
6 532 12 49-57 Fitting Grease (Front Wheel Only)
7 532 12 49-59 Bearing Flange (Front Wheel Only)
8 532 13 83-37 Rim Asm 8"rear Service
9 532 12 20-82 Tire R Ts 20 x 10-8 C Service
10 532 12 49-26 Tube Rear (Service Item Only)
11 532 17 50-39 Cap Axle Blk 1 50 x 1 00
- - 532 14 43-34 Sealant, Tire (10 oz. tube)
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
6
2
1
5,8
4,10
3,9
11
7
wheel_1
10
11
13
1
1
16
16
17
14
3
12
REPAIR PARTS
TRACTOR - MODEL NO. LT2122A2 (96011013100), PRODUCT NO. 960 11 01-31
DECALS
4
3
13
6
18
