JOOLA Infinity User Manual

Part Description Qty
Table Surface
Part #:11101-01
2
Net and Post Set
Part #:11101-02
1
Chassis
Part #:11101-03
1
Angled Track Bar
Part #:11101-04
4
4” Caster
Part #:11101-05
4
Logo Side Panel
Part #:11101-06
2
Straight Crossmember Bar
Part #:11101-07
4
Curved Crossmember Bar
Part #:11101-08
4
Logo ‘H’ Legs
Part #:11101-09
2
Nylon Locking Nut
Part #:11101-10
28
17mm Washer
Part #:11101-11
56
15mm Spacer
Part #:11101-12
12
5mm Spacer
Part #:11101-13
8
10mm x 60mm Bolt
Part #:11101-23
4
8mm x 90mm Bolt
(Partial or Fully Threaded)
Part #:11101-14
8
8mm x 80mm Bolt
Part #:11101-15
12
8mm x 50mm Bolt
Part #:11101-16
4
8mm x 25mm Bolt
Part #:11101-17
4
6mm x 45mm Screw
Part #:11101-18
4
Track Cover
Part #:11101-19
4
Please contact JOOLA North America, LLC
and have the following information ready:
• Product Name
• Part number (from assembling
instructions)
• Credit card information (number,
expiration date, CVC code, billing
name and address) for payment
processing (if after warranty)
• Shipping address for replacement
parts
JOOLA Consumer Service Department
15850 Crabbs Branch Way Suite 170
Rockville, MD 20855
1-877-US-JOOLA or (301) 816 – 3060
info@joolausa.com
www.joolausa.com
REORDERING PARTS
PARTS LIST
6mm x 45mm
Part #: 11101-18
8mm x 25mm
Part #: 11101-17
8mm x 50mm
Part #:11101-16
8mm x 80mm
Part #: 11101-15
8mm x 90mm
Part #: 11101-14
TOP VIEW
SIDE VIEW
5mm Spacer
Part #: 11101-13
TOP VIEW SIDE VIEW
15mm Spacer
Part #: 11101-12
17mm Metal Washer
Part #: 11101-11
Nylon Locking Nuts
Part # 11101-10
Track Covers
Part #: 11101-19
10mm x 60mm
Part #: 11101-22
