Place each Solo face down on a scratch-free surface
and align, as shown in Figure A.
STEP 1
Locate the Quad Door Connection Kit and lay out the
connection bars on the Solos, as shown in Figure A.
Attach each connection bar using (4) M4x6mm Allen
screws and hand tighten using the included Allen
wrench.
STEP 2
Your Joovv system comes with extra screws.
Do not use a drill to install the screws as this can
strip the threads.
#1 Lead Mode #2 Follow Mode
#4 Follow Mode#3 Follow Mode
FIG. A
Door Mount
(2 people required)
SETTING UP YOUR JOOVV QUAD
7.2
