Locate the power patch cords in the Quad Door
connection kit. Connect each cord by inserting the
female ends into #1 Solo and #3 Solo, and male ends
into #2 Solo and #4 Solo, as shown in Figure B.
STEP 3
#1 Lead Mode #2 Follow Mode
#4 Follow Mode#3 Follow Mode
FIG. B
Door Mount
(2 people required)
SETTING UP YOUR JOOVV QUAD
7.3
