Caboose Ultralight Instruction Manual
Page 8
Figure 16
Figure 17
Figure 18
Figure 19
!
WARNING
Avoid serious injury from falling
or sliding out. Always use the seat
belt and harness. This seat unit is
not suitable for children under 6
months.
Securing the Front Seated Child
• Ensure that both shoulder straps are attached to
the waist strap buckles. See Figure 16.
• Unlatch the waist/shoulder buckle by squeezing
the latch releases on both sides of the buckle
and removing the male ends of each buckle.
• Carefully place the child in the seat with the
shoulder straps over their shoulders and chest.
Then place the crotch strap between the child’s
legs.
NOTE: There are three height adjustment
positions for the shoulder harness straps. For
a younger child, the shoulder straps should be
positioned through the lower sewn-in loops on
the seatback. For a young child that is tall, the
shoulder straps may be positioned through the
upper sewn-in loops on the seatback. For a
taller child, use the shoulder straps WITHOUT
positioning them through these sewn-in loops. To
re-position the shoulder straps, unbuckle them
from the harness buckle and feed these straps
through the sewn-in loops, ensuring that they are
not twisted. Re-buckle the shoulder straps onto
the harness buckle to secure them.
• Bring the seat belt around the child’s waist and
insert the male ends of the waist/shoulder buckle
into the female buckle. Ensure that they snap into
place. See Figure 17. Tighten the waist belt to be
snug around the child’s waist.
• Both the shoulder straps and the waist/crotch
straps may be adjusted using the sliding buckles
on these straps. See Figures 18 and 19.
