13 CAUTIONARY TOWING TIPS
• Stop trailer use immediately on poor road conditions, in severe weather or in any other dangerous environments.
• Ensure the trailer is completely disengaged from bicycle when not in use.
• Always store tow bar in a clean dry place.
• Before and after each use, inspect tow bar and discontinue use should it malfunction or become damaged.
• Not for use at high speeds. DO NOT exceed 10 MPH (16 km/h).
• Each child must wear an approved safety helmet when riding in the product in trailer mode.
• Always ensure your bicycle brakes function properly. Braking distance is increased when pulling a trailer.
• The trailer is wider than most bicycles. Allow extra clearance when near curbs, signs, parked cars and other obstacles.
• Do not turn sharply. A bicycle with a trailer requires a wide turning radius.
• Install a rearview mirror on your bicycle to check on children in the trailer.
Assembling and Using the Trailer Mode Attachment
To ensure safe operation of your trailer, please follow these instructions carefully.
!
WARNING
Adult assembly is required for this product. No tools required for bicycles with a quick release axle on the rear wheel.
Bicycles without a quick release axle on the rear wheels will require an adjustable wrench.
!
WARNING
Use caution not to get pinched by the locking clamp.
14 Removing the Coupler Attachment from the Tow Bar
• Locate the coupler attachment on the tow bar.
• To remove, carefully rotate the locking clamp off the tow bar. See Figure 14.1. Pull the locking pin out from the tube.
• Remove the coupler attachment from the tow bar tube. See Figure 14.2.
15 Installing/Uninstalling Coupler Attachment for Bicycles with Quick Release Rear Axles
• Flip the rear axle quick release lever open and remove the nut and spring from the opposite side. See Figure 15.1.
• Hold the lever and pull out the axle skewer with spring. See Figure 15.2.
• Completely remove the skewer while leaving the wheel in place.
• Placethecouplerovertheleftsideoftheaxlewiththeatsideofthecouplerattachmentfacinginwardagainsttheframeofthebicycle.
Insert the skewer through the wheel hub (and the coupler) and hook it onto the bicycle frame dropout. See Figure 15.3.
NOTE: The wide end of the spring should face outward and touch the quick release hub. See Figure 15.4.
• Replace the spring and then the nut onto the skewer. Turn the nut to tighten and then close the quick release lever. See Figure 15.5.
• Check the rear wheel to ensure it is tight and operating correctly.
• To remove this accessory, reverse the instructions in this section.
16 Installing/Uninstalling Coupler Attachment for Bicycles with Rear Hub Nuts
• Loosen the left rear wheel hub nut with a wrench.
• Remove the hub nut and washer from the axle. See Figure 16.1.
• Placethecouplerattachmentontotheaxlewiththeatsidefacinginwardagainsttheframeofthebicycle.See Figure 16.2.
• Replace the washer and the bicycle hub nut onto the axle and turn the nut to tighten. See Figure 16.3.
• Tighten the hub nut securely with a wrench.
• Check the rear wheel to ensure it is tight and operating correctly.
• To remove this accessory, reverse the instructions in this section.
17 Attaching/Detaching the Tow Bar to the Stroller/Trailer
• Tilt the stroller so it is resting on the handlebar and the rear wheels.
• Remove the front swivel wheels by pressing the release button located on the back of the front wheel housing and pulling the wheel away
from the stroller. Repeat for the other side.
• Remove the locking pin from the attachment housing (located on the lower front end of the stroller) by pulling the safety clamp over the pin
and sliding the pin out. See Figure 17.1.
• Insert the tow bar into the housing until the holes on the sides line up. See Figure 17.2.
• Insert the locking pin through the holes and attach the safety clamp over the pin to ensure it is secure. See Figure 17.3.
• Pull the tow bar away from the stroller to ensure it is securely installed.
• To remove this accessory, reverse the instructions in this section.
