Nook Instruction Manual
Securing the Child in the Seat
Note that there are two height adjustment positions for
the shoulder harness straps. For a younger child, the
shoulder harness straps should be positioned through
the lower openings. For a taller child, the shoulder
straps should be positioned through the top openings
toensureagoodt.
• To change the positioning of the shoulder straps,
ndtheendsofeachstrapunderthecoverand
behind the seat back. Twist the buckle on the end
of each strap sideways and push it out toward the
front of the seat back through the slot. To
re-assemble into a different slot position, twist the
buckle sideways and push it through the slot in the
seat back from the front toward the back of the high
chair. Release the buckle and make sure each strap
is not twisted. Pull each strap toward the front of
the high chair to be sure it is secure. Be sure that
both shoulder straps are inserted through the slots
at the SAME height.
• Ensure that both shoulder straps are attached to the
waist strap buckles. See Figure 9.
• Unlatch the waist/shoulder buckle by squeezing in
on both sides of the buckle latch and removing the
male ends of each buckle. See Figure 10.
• Carefully place the child in the high chair with the
shoulder straps over their shoulders and chest.
Then, place the crotch strap between the child’s legs.
• Bring the seat belt around the child’s waist and
insert the male ends of the waist/shoulder buckle
into the female buckle. Ensure that they snap into
place. See Figure 11. Tighten the waist belt to be
snug around the child’s waist.
• Both the shoulder straps and the waist/crotch straps
may be adjusted using the sliding buckles on these
straps. See Figure 12.
Figure 9
Figure 10
Figure 11
Figure 12
Pg. 4
!
WARNING
Prevent serious injury from falls or sliding out.
Always secure child using the restraint system.
