Jøtul 520 Series User Manual

13
ENGLISH
Fig. 4-b
1
2
• Pull out the primary air valve handle
• Place the distance clip to the shaft, as shown on (fig. 4-b) to
keep the valve in open position (UK only).
Fig. 4-c
Installation of leg rack (optional)
If building a brick surround, the leg base (optional, item no.
51044759) must be used. See Fig. 1 e and f.
Door hinges
The door is left-hinged as standard but can be changed to right-
hinged if required. If so, it should be changed before placing the
stove inside the hearth or surround.
An optional kit is required to change the door hinging.
Item no. 50045754. (See the manual, item no. 10045851, which
comes with the assembly kit.)

Jøtul 520 Series Specifications

General

Material	Cast Iron
Fuel Type	Wood
Log Grate Included	Yes
Ash Pan Included	Yes
Finish	Black Paint, Blue/Black Enamel, Ivory Enamel
Efficiency	75%
Emissions	2.5 g/h
Burn Time	Up to 8 hours
