33
ENGLISH
Fig. 50
A
B
2. Take hold of the hole (B) at the front edge of the inner bottom
(A) and lift it up.
Fig. 51
A
3. Turn one corner towards you and pull the inner bottom out.
4. When refitting, follow the same procedure in reverse order.
8.0 Optional extras
8.1 Leg Rack, complete
Item no. 51044759
8.2. Door lock, complete, left
For right-hinged door
Item no. 50045754
8.3 Frames
Frame for the Jøtul I 520 F
Item no. 50045750
Frame for the Jøtul I 520 FL/FR
Item no. 50045751
Frame for the Jøtul I 520 FRL
Item no. 50045752
8.4 Convection top plate, complete I 520 F
Item no. 50045755
8.5 Sheet metal grid
Sheet metal grid Jøtul I 520 F
Item no. 50045747
Sheet metal grid Jøtul I 520 FR
Item no. 50045748
Sheet metal grid Jøtul I 520 FL
Item no. 50045749
