Thank you for purchasing our BGA/SMD Rework System. Please carefully read
this manual before operating the system. Store this manual in a safe, easily
accessible place for future reference.
RE-800 BGA Rework Station (all you need in one machine)
RE-8500 is one of the most powerful machines in the BGA rework field as it
has many important and advanced features which help the user to get the best
performance in an easy way.
RE-8500 Features:
- Create an IPC/JEDEC standard profile (leaded or lead-free).
- Create a free mode profile (User defined profile).
- Manual control (drive RE-8500 to get your own profile).
- Save up to 50 profiles in the machine memory.
- Process & profile analyser for process study and analysis.
- PID intelligent temperature control.
- Powerful heaters with long life time (3600 watt).
- Accurate temperature readings of +/- 2°C.
- Five channels thermocouple real time temperature reading.
- Password protection for data and settings lock.
- Alarm set point to increase the process safety and control.
- Safety set point for user safety and security.
- Optimum heating with 3 controlled heating zones.
- Equipped with different types of reflectors for focusing and spotting the
heating image.
- High ramp preheating and reflow up to 2.5°C/sec, by using manual
control.
- Ideal application cooling stage in two methods optionally direct and
indirect air flow, adjustable airflow power fan.
- Very simple machine interface.
- All Windows multi lingual Jovy® PC Suite software interface via usb2.0.
- Wide lower heating area (500mmx 450mm).
- Serves all kinds of boards (small, medium and big).
