Arcade-GameStaon
6. Assembly instrucons
Step 5 | connecng the signal cable to the microswitches
One cable contains four plugs. Two for the signal and the other two for the ground. The
two ground-plugs are on one cable, the two signal-plugs have their own cables. Up to
two buons become a connected to a unit.
Please see the right image below to nd out which buons you have to connect in
which way.
Connect the signal-plugs on the center contacts.
The ground-plugsare conntected to the boom contacts of the microswitches.
Ground1
Signal-plug 1 Signal-plug 2
Ground
