4.2 Code example
Please copy the following sample code completely into your Arduino IDE.
You can then upload this code example to your Arduino. Please make
sure that port and board are set correctly under Tools. Alternatively you
can download the code sample here.
Aer successful transfer of the code, the module will alternately start a
10-second recording and play it back aerwards.
4.1 Connecting the module
Connect the capture device to the pins of the Arduino as shown in the
following picture or table.
4. USE WITH THE ARDUINO
Arduino Soundmodule
5V VCC
GND GND
13 P-E
12 REC
