30
PEGASUS / TYPICAL / JOYEE
建議固定方式
Please use the universal tie for fixing.
調整機台 P 點位置
Adjust P position of the machine
電線、風管固定方式
Fix the electric wire and air tube.
X
①馬達運轉一圈確認是否在P點位置
Please confirm the P position after rotating motor a circle.
2-1 確認 -數字位置
※若未在P點位置時:
3-1 將手輪放鬆
2-2 將針柱轉至P點
2-2
3-1
3-2
3-3
3-2 轉至-數字原本位置
3-3 將手輪鎖緊
X
2-1
If it is not on the P position:
Check-X position
Turn the needle till P position
Loosen the hand wheel
Turn the - X back to original positi
