Figure 21
Clutch replacement
Do not remove the whole engine from vehicle when you replace the clutch, but you’ll
need to remove rear suspension, driven shaft, clutch cable, muffler, wires and rubber
cushion that is in the middle of transmission and frame.
1. Remove bolt M14 (See Fig. 22)
Figure 22
2. Remove two bolts (M12) on the starter (See Fig. 23), Remove the starter (See Fig.
24)
34
