Joyor S10-S User Manual

16 17
ENEN
ODO: To clear ODO
IntheODOparametersettinginterface,brieypressthe
buttonandthenpressandholdfor5-6secondsuntilthe
numberiszero.
NO.
Error
Code
Definition
1 ERRO 1 Motorfailure
2 ERRO 2 Acceleratorthrottlefailure
3 ERRO 3 Controllerfailure
4 ERRO 4 Brakefailure
5 ERRO 5 Undervoltageprotection
6 ERRO 6
Communicationfailure,thedisplaycannot
receivetheoutputfromthecontroller
7 ERRO 7
Communicationfailure,thecontroller
cannotreceivetheoutputfromthedisplay
Error Codes
Thenumbercorrespondingtothemulti-functionarea
representsthecorrespondingfaultcontent.Thespecic
statusisasfollows:

Joyor S10-S Specifications

General

Category	Electric Scooter
Max Load	120 kg
Tire Size	10 inch
Suspension	Front and Rear Suspension
Display	LCD Display
Material	Aluminum Alloy
IP Rating	IP54
Motor Power	1000W (Dual 500W Motors)
Max Speed	65 km/h
Brake System	Disc Brake
Lights	Front and Rear LED Lights
Range	70-85 km
