Joyor S5 User Manual

02 03
ENEN
1. LCDdisplay
2. Leverlockforhandlebarheightadjustment
3. Handlebarsleeve
4. Brake wire
5. Brakehandle
6. Frontsuspension
7. Frontlight
8. Frontmudguard
9. Frontairtyre
10. Frontdiscbrake(hydrauliconS10-S)
11. Frontmotor(onlyS10-S)
12. Foldingsystem
13. Rear light
14. Sidelights
15. Parkingstand
16. Rearmotor
17. Rearairtyre
18. Rearmudguard
19. Reardiskbrake(hydrauliconS10-S)
20. Rearsuspension
1
THE MAIN PARTS & TECHNICAL
SPECIFICATIONS
1.1 The Main Parts S5/S10-S
8
18
6 12 14 15 17
20
9
13
7
11
16
10 19
1
2
4
3
5

Joyor S5 Specifications

General

Battery Capacity	48V 13Ah
Tire Size	10 inch
Brakes	Front and rear disc brakes
Suspension	Front and rear suspension
Max Load	120 kg
IP Rating	IP54
